Practical 4 GHz FAKRA To FAKRA Cable , HD Camera FAKRA Z Female Cable

Place of Origin China
Brand Name LDS
Certification E-Mark
Model Number LDS-FAKRAZ-FSA
Minimum Order Quantity 20 PCS
Price Contact the seller
Packaging Details Carton size 29*13*11CM,20pcs per carton
Delivery Time 7~14 work days
Payment Terms L/C, T/T
Supply Ability 20000 PCS/Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Impedance 50Ω Frequency DC To 4 GHz
Insulation Resistance ≥100 MΩ Min Voltage Rating 60 V Max
Current Rating ≤1A DC Max Durability 25 Times(cycles)
Working Temperature -40℃ ~ +105℃
High Light

Practical FAKRA To FAKRA Cable

,

4 GHz FAKRA To FAKRA Cable

,

HD Camera FAKRA Z Female Cable

Leave a Message
Product Description

Fakra Cable With Fakra Z Female To Fakra Sealed Adapter For HD Camear



Description:

The Fakra Cable Assembly is used for Coax Cable Assemblies are Connecting Fakra and Fakra or others connectors.Fakra Cable Assembly has the characteristics of high shielding and strong reliability.The provide connectivity solutions for automotive infotainment modules, cameras, Global Positioning Satellite, display devices and Remote Vehicle.



Key Feature:

1.High-speed shielded connection system suitable for digital data with performance up to 4 Gbps.

2.High reliable connection, good contact and firm not loose.

3.Flexible combination of different interfaces.

4.Coaxial cables have high shielding.

5.Primary and secondary locking systems lead to high assembling security.

6.Multiple housings for space savings and for quick plug-in operations.

7.Usable on several coaxial cables(RG58,RG174,RG316,RTK031, RG178 and so on).

8.Meet RoHS environmental requirements.



Technical Specifications:



Electrical Performance
 Impedance  50 Ω
 Frequency Range  DC to 4 GHz
 Return Loss

 ≥-26 dB ,DC to 1 GHz

 Insertion Loss  ≤0.1 x √f(GHz) dB
 Insulation Resistance  ≥ 100 MΩ
 Center Contact Resistance  ≤ 5 mΩ
 Voltage Rating  335 V rms
 Working Voltage  100 V rms
 Contact Current  ≤ 1 A DC
Mechanical Performance
 Mating Cycles  ≥ 25 Time
 Cable Retention Force  ≥80 N



FAQ:

1.Q:How do I apply for samples?

   A:You can cantact our customer service,you only need to pay the freigth, our samples are free.



2.Q:Does your factory accept customized service?

   A:Yes,we accept OEM&ODM.



3.Q:What are yout company's strengths?

   A:We have a professional technical team to ensure quality as well as efficiency.
